Aeromotive 5.0L/min Brushless Spur Gear External Fuel Pump – Includes Mounting Feet (Part #11186)

Description

Aeromotive Pro-Series 5.0 gpm brushless gear pumps are engineered from the ground up for winning performance. In fact, they’re the single highest-flowing electric fuel pumps on the market. These efficient pumps utilize a spur gear design, paired with a brushless motor, to deliver 5.0 gpm at 60 psi. Their inline flow-through design features contoured port machining and no shaft seals, while offering low-amp draw, excellent heat dissipation, and high-pressure capabilities. Lots of power needs lots of fuel; Aeromotive 5.0 gpm brushless gear pumps will feed your hungry high performance machine. * *Fuel injected engines:*Up to 2400 FWHP (11181) / 3400 FWHP (11182) – naturally aspiratedUp to 1800 FWHP (11181) / 2600 FWHP (11182) – forced air induction * *Carbureted engines:*Up to 2600 FWHP (11181) / 3600 FWHP (11182) – naturally aspiratedUp to 2000 FWHP (11181) / 2700 FWHP (11182) – forced air induction * E85 Compatible, reduce max FWHP by 30% * Lighter than the traditional Pro-Series pump. * Reduced current draw at higher, EFI pressures. * Extended service life in methanol and ethanol. * New integral spur-gear pumping mechanism. * 90-PSI continuous operating pressure and up to 150-PSI peak pressure, base plus boost. * Integral, external brushless controller for clean installation, cooler fuel and enhanced reliability. * ORB-12 inlet and ORB-10 outlet ports.EFI Rated flow of 1,250 lbs./hr. (11181) / 1,700 lbs./hr. (11182) @ 40 psi, 13.5 voltsCarb Rated Flow of 1,350 lbs./hr. (11181) / 1,850 lbs./hr. (11182) @ 9 psi, 13.5 volts
